How to Deinstall Oracle software To Deinstall Oracle software we need to go first Oracle software location
|
1 |
[oracle@dba2 oracle]$ cd /u01/app/oracle/product/12.1.0/ |
List out the files
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 |
[oracle@dba2 12.1.0]$ ll total 288 drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:42 addnode drwxr-xr-x. 8 oracle dba 4096 Oct 11 16:42 apex drwxr-xr-x. 9 oracle dba 4096 Oct 11 16:40 assistants drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:44 bin drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:42 ccr drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:42 cdata drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:45 cfgtoollogs drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:42 clone drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:40 crs drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:42 css drwxr-xr-x. 11 oracle dba 4096 Oct 11 16:42 ctx drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:40 cv drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:40 dbs drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:42 dc_ocm drwxr-xr-x. 5 oracle dba 4096 Oct 11 16:44 deinstall drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 demo drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 diagnostics drwxr-xr-x. 8 oracle dba 4096 Oct 11 16:41 dmu drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 dv drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 has drwxr-xr-x. 5 oracle dba 4096 Oct 11 16:44 hs drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:45 install drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 instantclient drwxr-x---. 13 oracle dba 4096 Oct 11 16:44 inventory drwxr-xr-x. 8 oracle dba 4096 Oct 11 16:40 javavm drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:42 jdbc drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:42 jdk drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:42 jlib drwxr-xr-x. 12 oracle dba 4096 Oct 11 16:42 ldap drwxr-xr-x. 3 oracle dba 12288 Oct 11 16:44 lib drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:40 log drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:40 md drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:42 mgw drwxr-xr-x. 10 oracle dba 4096 Oct 11 16:44 network drwxr-xr-x. 5 oracle dba 4096 Oct 11 16:40 nls drwxr-xr-x. 19 oracle dba 4096 Oct 11 16:41 oc4j drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:40 odbc drwxr-xr-x. 5 oracle dba 4096 Oct 11 16:40 olap drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:42 OPatch drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:42 opmn drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:40 oracore -rw-r-----. 1 oracle dba 56 Oct 11 16:40 oraInst.loc drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:40 ord drwxr-xr-x. 8 oracle dba 4096 Oct 11 16:44 oui drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:40 owm drwxr-xr-x. 5 oracle dba 4096 Oct 11 16:40 perl drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:40 plsql drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 plugins drwxr-xr-x. 6 oracle dba 4096 Oct 11 16:40 precomp drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 QOpatch drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 R drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:42 racg drwxr-xr-x. 14 oracle dba 4096 Oct 11 16:44 rdbms drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 relnotes drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 rest -rwxr-x---. 1 oracle dba 409 Oct 11 16:44 root.sh drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:40 scheduler drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 slax drwxr-xr-x. 15 oracle dba 4096 Oct 11 16:42 sqldeveloper drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 sqlj drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:40 sqlpatch drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:43 sqlplus drwxr-xr-x. 9 oracle dba 4096 Oct 11 16:42 srvm drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:40 suptools drwxr-xr-x. 4 oracle dba 4096 Oct 11 16:40 sysman drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:42 ucp drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 usm drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 utl drwxr-xr-x. 3 oracle dba 4096 Oct 11 16:40 wwg drwxr-xr-x. 7 oracle dba 4096 Oct 11 16:41 xdk |
Go-to Deinstall directory
|
1 |
[oracle@dba2 12.1.0]$ cd deinstall/ |
List out the files unser deinstall directory
|
1 2 3 4 5 6 7 8 9 10 11 12 |
[oracle@dba2 deinstall]$ ll total 348 -rw-r--r--. 1 oracle dba 240220 Jul 7 2014 bootstrap_files.lst -rwxr-xr-x. 1 oracle dba 11952 Mar 4 2014 bootstrap.pl -rwxr-xr-x. 1 oracle dba 10222 Oct 11 16:44 deinstall -rwxr-xr-x. 1 oracle dba 28591 May 19 2014 deinstall.pl -rw-r--r--. 1 oracle dba 8623 Apr 11 2014 deinstall.xml drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 jlib -rw-r--r--. 1 oracle dba 401 Feb 10 2012 readme.txt drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 response -rwxr-xr-x. 1 oracle dba 32334 Jun 7 2013 sshUserSetup.sh drwxr-xr-x. 2 oracle dba 4096 Oct 11 16:41 utl |
Run the file ./deinstall
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 |
[oracle@dba2 deinstall]$ ./deinstall Checking for required files and bootstrapping ... Please wait ... Location of logs /tmp/deinstall2019-01-10_07-43-23PM/logs/ ############ ORACLE DECONFIG TOOL START ############ ######################### DECONFIG CHECK OPERATION START ######################### ## [START] Install check configuration ## Checking for existence of the Oracle home location /u01/app/oracle/product/12.1.0 Oracle Home type selected for deinstall is: Oracle Single Instance Database Oracle Base selected for deinstall is: /u01/app/oracle Checking for existence of central inventory location /u01/app/oraInventory ## [END] Install check configuration ## Network Configuration check config START Network de-configuration trace file location: /tmp/deinstall2019-01-10_07-43-23PM/logs/netdc_check2019-01-10_07-46-36-PM.log Network Configuration check config END Database Check Configuration START Database de-configuration trace file location: /tmp/deinstall2019-01-10_07-43-23PM/logs/databasedc_check2019-01-10_07-46-36-PM.log Use comma as separator when specifying list of values as input Specify the list of database names that are configured in this Oracle home []: Database Check Configuration END Oracle Configuration Manager check START OCM check log file location : /tmp/deinstall2019-01-10_07-43-23PM/logs//ocm_check1526.log Oracle Configuration Manager check END ######################## DECONFIG CHECK OPERATION END ######################### ####################### DECONFIG CHECK OPERATION SUMMARY ####################### Oracle Home selected for deinstall is: /u01/app/oracle/product/12.1.0 Inventory Location where the Oracle home registered is: /u01/app/oraInventory Checking the config status for CCR Oracle Home exists with CCR directory, but CCR is not configured CCR check is finished Do you want to continue (y - yes, n - no)? [n]: y A log of this session will be written to: '/tmp/deinstall2019-01-10_07-43-23PM/logs/deinstall_deconfig2019-01-10_07-46-31-PM.out' Any error messages from this session will be written to: '/tmp/deinstall2019-01-10_07-43-23PM/logs/deinstall_deconfig2019-01-10_07-46-31-PM.err' ######################## DECONFIG CLEAN OPERATION START ######################## Database de-configuration trace file location: /tmp/deinstall2019-01-10_07-43-23PM/logs/databasedc_clean2019-01-10_07-47-04-PM.log Network Configuration clean config START Network de-configuration trace file location: /tmp/deinstall2019-01-10_07-43-23PM/logs/netdc_clean2019-01-10_07-47-04-PM.log De-configuring backup files... Backup files de-configured successfully. The network configuration has been cleaned up successfully. Network Configuration clean config END Oracle Configuration Manager clean START OCM clean log file location : /tmp/deinstall2019-01-10_07-43-23PM/logs//ocm_clean1526.log Oracle Configuration Manager clean END ######################### DECONFIG CLEAN OPERATION END ######################### ####################### DECONFIG CLEAN OPERATION SUMMARY ####################### Cleaning the config for CCR As CCR is not configured, so skipping the cleaning of CCR configuration CCR clean is finished ####################################################################### ############# ORACLE DECONFIG TOOL END ############# Using properties file /tmp/deinstall2019-01-10_07-43-23PM/response/deinstall_2019-01-10_07-46-31-PM.rsp Location of logs /tmp/deinstall2019-01-10_07-43-23PM/logs/ ############ ORACLE DEINSTALL TOOL START ############ ###################### DEINSTALL CHECK OPERATION SUMMARY ####################### A log of this session will be written to: '/tmp/deinstall2019-01-10_07-43-23PM/logs/deinstall_deconfig2019-01-10_07-46-31-PM.out' Any error messages from this session will be written to: '/tmp/deinstall2019-01-10_07-43-23PM/logs/deinstall_deconfig2019-01-10_07-46-31-PM.err' ######################## DEINSTALL CLEAN OPERATION START ######################## ## [START] Preparing for Deinstall ## Setting LOCAL_NODE to dba2 Setting CRS_HOME to false Setting oracle.installer.invPtrLoc to /tmp/deinstall2019-01-10_07-43-23PM/oraInst.loc Setting oracle.installer.local to false # [END] Preparing for Deinstall ## Setting the force flag to false Setting the force flag to cleanup the Oracle Base Oracle Universal Installer clean START Detach Oracle home '/u01/app/oracle/product/12.1.0' from the central inventory on the local node : Done Delete directory '/u01/app/oracle/product/12.1.0' on the local node : Done Delete directory '/u01/app/oraInventory' on the local node : Done Delete directory '/u01/app/oracle' on the local node : Done Oracle Universal Installer cleanup was successful. Oracle Universal Installer clean END ## [START] Oracle install clean ## Clean install operation removing temporary directory '/tmp/deinstall2019-01-10_07-43-23PM' on node 'dba2' ## [END] Oracle install clean ## ######################### DEINSTALL CLEAN OPERATION END ######################### ####################### DEINSTALL CLEAN OPERATION SUMMARY ####################### Successfully detached Oracle home '/u01/app/oracle/product/12.1.0' from the central inventory on the local node. Successfully deleted directory '/u01/app/oracle/product/12.1.0' on the local node. Successfully deleted directory '/u01/app/oraInventory' on the local node. Successfully deleted directory '/u01/app/oracle' on the local node. Oracle Universal Installer cleanup was successful. Run 'rm -r /etc/oraInst.loc' as root on node(s) 'dba2' at the end of the session. Run 'rm -r /opt/ORCLfmap' as root on node(s) 'dba2' at the end of the session. Run 'rm -r /etc/oratab' as root on node(s) 'dba2' at the end of the session. Oracle deinstall tool successfully cleaned up temporary directories. ####################################################################### ############# ORACLE DEINSTALL TOOL END ############# |
Installation of Oracle software… Read More
