How to Create Amazon Linux EC2 Instance Using AWS CLI

Share via:

Post Views: 0

Dear Readers,

In this article, we will see the following Create Amazon Linux EC2 Instance in AWS CLI.

Steps to Follow :

Connect to AWS CLI On Windows
Create a Key Pair
Create a Security Group
Create a Amazon EC2 Instance
Create a Volume
Attach volume to ec2 Instance

1. Connect to AWS CLI On Windows

To configure AWS CLI On Windows click here

Go inside the Command Line Interface

Specify required credentials, region and output format for connect to AWS CLI

C:\Users\user>aws configure
AWS Access Key ID [None]: AKIAIGUQ7POGL3A6I3GQ
AWS Secret Access Key [None]: 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
Default region name [None]: ap-south-1
Default output format [None]: table

C:\Users\user>aws configure

AWS Access Key ID [None]: AKIAIGUQ7POGL3A6I3GQ

AWS Secret Access Key [None]: 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

Default region name [None]: ap-south-1

Default output format [None]: table

2. Create Key Pair

C:\Users\user>aws ec2 create-key-pair --key-name ktexperts_key

{
"KeyFingerprint": "ea:8e:97:2b:61:c0:bd:02:38:7b:f5:a3:28:3e:0f:c7:b2:62:97:82",
"KeyMaterial": "-----BEGIN RSA PRIVATE KEY-----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\neFIxU/QTRjuRN
excOfsJbd1WnMiJUm41g7IyNcjn3JNYqjkumHJzFN5oH8DLU30P\nfA2BlSapzkOA8ya
UvGIz7y1SXgq/mfn8wVg0tgRyN1g0RshpdvCvk4b0LJ5mLR3H\n62Pk6P0b/Dvqa29Bb
/F38lh3XERYwAfxQFWdZhECgYEAxD68GPJy+QNMVkoMznWX\ndAT9qWRCHhwdibXrtVI
Sjd2kV8IZgaD7zKM5wrTeIw2YFQmVBtlbA+jY25btKAkc\nrbh/rUxiteC09oz3D9kX4
8GXo3C/oMW1QlzO4izMG3wu8cERGSnqSfmSZuAKZUBo\nFYyDM1XEvF2zkypecCnmG3M
CgYEAncssncv+apFEKmfQ0Jibn7Z81kxBcCrGcNy0\nNAkx23Q8CDUtrErYOHxBalzoN
1IPaxSE00Q2GBvt2ir/RHEBRxcModt2Gzh96txi\nk0jDmWxj/3XnFol3g1CWiEsH/z0
1puWeUZQN6ql4BLv6lGhSAIETLUVjfLB14ZH\n2ygkZYECgYAGt1j9h0Y6CDSf/WdlzL
0KSJKcj7K5fCTzMNAOlIb787oVsoRCOXhY\nDui5tZkvnJFUOkHZ1r80WzCcyKXgwlGF
vFZlMm+Mcd+3jnPSstwo7WXeVlmwPgMr\n2CkUsbaahM8F3RnIZihrPb38j3Ldurczyx
QtzJGJg8+I8e9Rn90J6Q==\n-----END RSA PRIVATE KEY-----",
"KeyName": "ktexperts_key",
"KeyPairId": "key-040d0328ad262ec96"

C:\Users\user>aws ec2 create-key-pair --key-name ktexperts_key

{

"KeyFingerprint": "ea:8e:97:2b:61:c0:bd:02:38:7b:f5:a3:28:3e:0f:c7:b2:62:97:82",

"KeyMaterial": "-----BEGIN RSA PRIVATE KEY-----

MIIEowIBAAKCAQEAoQQaHEnGi2aau2tKAEGmFcr+rdiA6tyFCGvVWAFE1Qqn6KzQ

8IuIT/+FMNH/wu+cpxXehszXXzl3NWdyhnQ6cL1J3dzHYQHyCfE3SJjUnUm9gcq7

FQm4RLTrcMJ1PUqc+FDebpxHEzYGuj4OE46ge1I5M61TL1NeEACCexo1wwnf11f/

cG8sE7xbZRi/abO+EL3U1brjkoZXABJoz6rDa6lSJoEYpu7WIg+LkrrouXl7ACb8

xZYEcT/3IufSqbqQAwWsWW9WRowbAmox0qOEu7vYAC8d1lzzCYV6aPp4/0jH90jE

ATe3CV2dzGnCtljAKALJq7rA6MbiPdzwd/PwzQIDAQABAoIBABK05UuwDo8XhpaL

qndJKUCS6u/LnX6rzBDkZk7pJtQRftx7Z3Lq4xVYPGMloq9FI1AOLGJA3izEAmOD

9zxDuJ5sf251Pfy5OyOIkMGwb9MuRAQWR5H0JSJmWowpK3HJf18iFhWHtoI23qU4

nG4NPfvV26tzUZzH9L+rL32Z1/Emv0YwlAKHyFP1CZoC+XYcuPSFpVEXHv4CRCdy

09nn01xvKRVwUkPhFWw3M3psD662Wh74o75jv22E2zIWYXI5VOefgZKHMc5h6uPU

iTnelUyVWXx6rAGrs2vzKStdW6u7UbMSm24r1a2BiyCTk0MO1XQMQ+t4z1wLLwj0

8Eft6kECgYEA14yRs/4WNSHiW8eg5Wv0kwXOFpULKE3QxfIyoCiPcLTGX3gtTpx7

G11BSOgsobGG4eILi8h40s4KDO6thfey46zzeeSeIkSaDLGYVAPl48jIab5rEEGs

E8jaqdISoC5ao2oC8UqK4BYYkvXBCrN8oL/9Duy8Wr6Hx8Aik/tFQpUCgYEAvzum

R5OSxB3Zz8TapsgUVMJ+cQf8DSJfSVBYlBwwu0VcNMMgOPzSxQN05xeB5qTCwlx8

DDjG7N77QOryBwJ+3B1v9opPRoOaMRbxCErhbkZP9PQX0swtcIM4QnvsQBEuyK7A

Doj5PAp+yLurnaFI6Dx1FmjC/oMxWW1jcJBg31kCgYEAq7QwhP9M1XpuhMobY2aB

53RiXR7RSoPiYSy0I1zsFs4KkBZ9kPeaIYxB6z/3/b4bQmj85ZcGmHbFDtQ6qlNM

z40ATwNM7ONVC/OU8qhAQxm4fHPReZu25fPELC9J4wvJ7A8Q1QGaazNu0/Ksmkes

aalGftMan/bS1s45PUSWQZkCgYBt6bb0xNlCZ3XdeWPDIJSu8usBxHkWg38JAGkp

F9raiE8q9Ev89TOfkREMEfLTwjc+xzF1RNzxIGiBM4jQhpqroS/NIEnYWaOyO2Fm

RsOzQi6KuBFJU5l6ZbFcZSWw3S9qoSY6NHgsDkw4y8Uj4KOq97TEoIoTBwzCPaE9

/X3wYQKBgDe36CvpSeGY60sHVHRMvCl12Q38sljaVsVZrUvfpVwC2j/zJXLBhequ

ANeigM7d3SN4kZsmacTOMq7l/SZh97U0ox+d+Ovd58iP/JWD8WPyb+Ad9+fNfIxy

E1rRYK9PI6Qa3CtfR6dMmZttSJPmZjn3CpMTKoPi8Jt3tANrRrkX\neFIxU/QTRjuRN

excOfsJbd1WnMiJUm41g7IyNcjn3JNYqjkumHJzFN5oH8DLU30P\nfA2BlSapzkOA8ya

UvGIz7y1SXgq/mfn8wVg0tgRyN1g0RshpdvCvk4b0LJ5mLR3H\n62Pk6P0b/Dvqa29Bb

/F38lh3XERYwAfxQFWdZhECgYEAxD68GPJy+QNMVkoMznWX\ndAT9qWRCHhwdibXrtVI

Sjd2kV8IZgaD7zKM5wrTeIw2YFQmVBtlbA+jY25btKAkc\nrbh/rUxiteC09oz3D9kX4

8GXo3C/oMW1QlzO4izMG3wu8cERGSnqSfmSZuAKZUBo\nFYyDM1XEvF2zkypecCnmG3M

CgYEAncssncv+apFEKmfQ0Jibn7Z81kxBcCrGcNy0\nNAkx23Q8CDUtrErYOHxBalzoN

1IPaxSE00Q2GBvt2ir/RHEBRxcModt2Gzh96txi\nk0jDmWxj/3XnFol3g1CWiEsH/z0

1puWeUZQN6ql4BLv6lGhSAIETLUVjfLB14ZH\n2ygkZYECgYAGt1j9h0Y6CDSf/WdlzL

0KSJKcj7K5fCTzMNAOlIb787oVsoRCOXhY\nDui5tZkvnJFUOkHZ1r80WzCcyKXgwlGF

vFZlMm+Mcd+3jnPSstwo7WXeVlmwPgMr\n2CkUsbaahM8F3RnIZihrPb38j3Ldurczyx

QtzJGJg8+I8e9Rn90J6Q==\n-----END RSA PRIVATE KEY-----",

"KeyName": "ktexperts_key",

"KeyPairId": "key-040d0328ad262ec96"

Verify Key Pair in graphical

3. Create a Security Group

C:\Users\user>aws ec2 create-security-group --group-name ktexperts --description "ktexperts"
{
    "GroupId": "sg-0872608d936b3095e"
}

C:\Users\user>aws ec2 create-security-group --group-name ktexperts --description "ktexperts"

{

"GroupId": "sg-0872608d936b3095e"

}

Verify in graphical

4. Create a Amazon EC2 Instance

Copy AMI of Amazon Linux2

C:\Users\user>aws ec2 run-instances --image-id  ami-0e306788ff2473ccb --instance-type t2 <a href ="https://ed-hrvatski.com/genericka-levitra/" style="color: #333; border-color: transparent; font-weight: normal; text-decoration: none">link za web stranicu</a>.micro --key-name ktexperts_key --security-group-ids sg-0872608d936b3095e
{
    "Groups": [],
    "Instances": [
        {
            "AmiLaunchIndex": 0,
            "ImageId": "ami-0e306788ff2473ccb",
            "InstanceId": "i-0c60b86b4ea1f91f4",
            "InstanceType": "t2.micro",
            "KeyName": "ktexperts_key",
            "LaunchTime": "2020-10-15T06:51:44.000Z",
            "Monitoring": {
                "State": "disabled"
            },
            "Placement": {
                "AvailabilityZone": "ap-south-1a",
                "GroupName": "",
                "Tenancy": "default"
            },
            "PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",
            "PrivateIpAddress": "172.31.36.36",
            "ProductCodes": [],
            "PublicDnsName": "",
            "State": {
                "Code": 0,
                "Name": "pending"
            },
            "StateTransitionReason": "",
            "SubnetId": "subnet-dad4c1b2",
            "VpcId": "vpc-dd12feb6",
            "Architecture": "x86_64",
            "BlockDeviceMappings": [],
            "ClientToken": "e8c3a6f4-b400-45ef-af09-1793546c2fcf",
            "EbsOptimized": false,
            "Hypervisor": "xen",
            "NetworkInterfaces": [
                {
                    "Attachment": {
                        "AttachTime": "2020-10-15T06:51:44.000Z",
                        "AttachmentId": "eni-attach-081855dc65adbf101",
                        "DeleteOnTermination": true,
                        "DeviceIndex": 0,
                        "Status": "attaching"
                    },
                    "Description": "",
                    "Groups": [
                        {
                            "GroupName": "ktexperts",
                            "GroupId": "sg-0872608d936b3095e"
                        }
                    ],
                    "Ipv6Addresses": [],
                    "MacAddress": "02:bd:2c:dc:10:d6",
                    "NetworkInterfaceId": "eni-0a7abb8bc0abaf331",
                    "OwnerId": "740581369608",
                    "PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",
                    "PrivateIpAddress": "172.31.36.36",
                    "PrivateIpAddresses": [
                        {
                            "Primary": true,
                            "PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",
                            "PrivateIpAddress": "172.31.36.36"
                        }
                    ],
                    "SourceDestCheck": true,
                    "Status": "in-use",
                    "SubnetId": "subnet-dad4c1b2",
                    "VpcId": "vpc-dd12feb6",
                    "InterfaceType": "interface"
                }
            ],
            "RootDeviceName": "/dev/xvda",
            "RootDeviceType": "ebs",
            "SecurityGroups": [
                {
                    "GroupName": "ktexperts",
                    "GroupId": "sg-0872608d936b3095e"
                }
            ],
            "SourceDestCheck": true,
            "StateReason": {
                "Code": "pending",
                "Message": "pending"
            },
            "VirtualizationType": "hvm",
            "CpuOptions": {
                "CoreCount": 1,
                "ThreadsPerCore": 1
            },
            "CapacityReservationSpecification": {
                "CapacityReservationPreference": "open"
            },
            "MetadataOptions": {
                "State": "pending",
                "HttpTokens": "optional",
                "HttpPutResponseHopLimit": 1,
                "HttpEndpoint": "enabled"
            }
        }
    ],
    "OwnerId": "740581369608",
    "ReservationId": "r-060ad4b3b14c891e9"
}

100

101

102

103

C:\Users\user>aws ec2 run-instances --image-id ami-0e306788ff2473ccb --instance-type t2 <a href ="https://ed-hrvatski.com/genericka-levitra/" style="color: #333; border-color: transparent; font-weight: normal; text-decoration: none">link za web stranicu</a>.micro --key-name ktexperts_key --security-group-ids sg-0872608d936b3095e

{

"Groups": [],

"Instances": [

{

"AmiLaunchIndex": 0,

"ImageId": "ami-0e306788ff2473ccb",

"InstanceId": "i-0c60b86b4ea1f91f4",

"InstanceType": "t2.micro",

"KeyName": "ktexperts_key",

"LaunchTime": "2020-10-15T06:51:44.000Z",

"Monitoring": {

"State": "disabled"

"Placement": {

"AvailabilityZone": "ap-south-1a",

"GroupName": "",

"Tenancy": "default"

"PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",

"PrivateIpAddress": "172.31.36.36",

"ProductCodes": [],

"PublicDnsName": "",

"State": {

"Code": 0,

"Name": "pending"

"StateTransitionReason": "",

"SubnetId": "subnet-dad4c1b2",

"VpcId": "vpc-dd12feb6",

"Architecture": "x86_64",

"BlockDeviceMappings": [],

"ClientToken": "e8c3a6f4-b400-45ef-af09-1793546c2fcf",

"EbsOptimized": false,

"Hypervisor": "xen",

"NetworkInterfaces": [

{

"Attachment": {

"AttachTime": "2020-10-15T06:51:44.000Z",

"AttachmentId": "eni-attach-081855dc65adbf101",

"DeleteOnTermination": true,

"DeviceIndex": 0,

"Status": "attaching"

"Description": "",

"Groups": [

{

"GroupName": "ktexperts",

"GroupId": "sg-0872608d936b3095e"

}

"Ipv6Addresses": [],

"MacAddress": "02:bd:2c:dc:10:d6",

"NetworkInterfaceId": "eni-0a7abb8bc0abaf331",

"OwnerId": "740581369608",

"PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",

"PrivateIpAddress": "172.31.36.36",

"PrivateIpAddresses": [

{

"Primary": true,

"PrivateDnsName": "ip-172-31-36-36.ap-south-1.compute.internal",

"PrivateIpAddress": "172.31.36.36"

}

"SourceDestCheck": true,

"Status": "in-use",

"SubnetId": "subnet-dad4c1b2",

"VpcId": "vpc-dd12feb6",

"InterfaceType": "interface"

}

"RootDeviceName": "/dev/xvda",

"RootDeviceType": "ebs",

"SecurityGroups": [

{

"GroupName": "ktexperts",

"GroupId": "sg-0872608d936b3095e"

}

"SourceDestCheck": true,

"StateReason": {

"Code": "pending",

"Message": "pending"

"VirtualizationType": "hvm",

"CpuOptions": {

"CoreCount": 1,

"ThreadsPerCore": 1

"CapacityReservationSpecification": {

"CapacityReservationPreference": "open"

"MetadataOptions": {

"State": "pending",

"HttpTokens": "optional",

"HttpPutResponseHopLimit": 1,

"HttpEndpoint": "enabled"

}

"OwnerId": "740581369608",

"ReservationId": "r-060ad4b3b14c891e9"

}

Verify the Amazon EC2 Instance in graphical

5. Create a Volume

Before creating volume we need to check the availability zone your ec2 instance because ec2 instance and volume should be in same availability zone.

Verify Availability Zone

Create a Volume

C:\Users\user>aws ec2 create-volume --volume-type gp2  --size 5 --availability-zone  ap-south-1a
{
    "AvailabilityZone": "ap-south-1a",
    "CreateTime": "2020-10-15T06:53:32.000Z",
    "Encrypted": false,
    "Size": 5,
    "SnapshotId": "",
    "State": "creating",
    "VolumeId": "vol-00455377bc62599c8",
    "Iops": 100,
    "Tags": [],
    "VolumeType": "gp2"
}

C:\Users\user>aws ec2 create-volume --volume-type gp2 --size 5 --availability-zone ap-south-1a

{

"AvailabilityZone": "ap-south-1a",

"CreateTime": "2020-10-15T06:53:32.000Z",

"Encrypted": false,

"Size": 5,

"SnapshotId": "",

"State": "creating",

"VolumeId": "vol-00455377bc62599c8",

"Iops": 100,

"Tags": [],

"VolumeType": "gp2"

}

Verify Volume in graphical

6. Attach volume to EC2 Instance

C:\Users\user>aws ec2 attach-volume --volume-id vol-00455377bc62599c8 --instance-id i-0c60b86b4ea1f91f4 --device /dev/sdf
{
    "AttachTime": "2020-10-15T06:57:56.438Z",
    "Device": "/dev/sdf",
    "InstanceId": "i-0c60b86b4ea1f91f4",
    "State": "attaching",
    "VolumeId": "vol-00455377bc62599c8"
}

C:\Users\user>aws ec2 attach-volume --volume-id vol-00455377bc62599c8 --instance-id i-0c60b86b4ea1f91f4 --device /dev/sdf

{

"AttachTime": "2020-10-15T06:57:56.438Z",

"Device": "/dev/sdf",

"InstanceId": "i-0c60b86b4ea1f91f4",

"State": "attaching",

"VolumeId": "vol-00455377bc62599c8"

}

Verify in graphical

Thank you for giving your valuable time to read the above information.
Follow us on
Website : www.ktexperts.com
Facebook Page : KTexperts
Linkedin Page : KT EXPERTS

Follow Me
Ramesh’s Linkedin : Ramesh Atchala

Share via:

Note: Please test scripts in Non Prod before trying in Production.

Ramesh Reddy

Share this post

Tags

How to Create Amazon Linux EC2 Instance Using AWS CLI

1. Connect to AWS CLI On Windows

2. Create Key Pair

3. Create a Security Group

4. Create a Amazon EC2 Instance

5. Create a Volume

6. Attach volume to EC2 Instance

Add Comment Cancel reply

Ramesh Reddy

Share this post

Tags

1. Connect to AWS CLI On Windows

2. Create Key Pair

3. Create a Security Group

4. Create a Amazon EC2 Instance

5. Create a Volume

6. Attach volume to EC2 Instance

You might also like...

Real-Time Use Case : IAM (Identity and Access Management)

AWS : Real Time Use Case On Storage

How to Create AWS EC2 Instance Using Cloud Formation

Add Comment Cancel reply
